MultiProcess Welding Equipment
Next Evolution of MultiProcess Welding Equipment
Böhler Welding MultiProcess inverter are highly practical solutions whenever welders have to use a number of different processes and therefore demand flexibility as well as high performance. They are also ideal for use by maintenance companies and in all schools and colleges that offer training courses in welding. The equipment is available in the URANOS NX line, offering the characteristics and performance needed to satisfy all industrial welding needs. The MultiProcess portfolio includes a huge number of special welding processes, dedicated software and other key components as torches and wire feeders.
We provide you a complete MultiProcess solution for your welding needs.
-
URANOS MultiProcess inverter are the perfect solutions whenever welders have to use a number of different processes and therefore demand flexibility as well as high performance.
- greenWave® patented technology for extremely high efficiency and energy cost saving
- Graphic color user 3,5” panel, an easy and intuitive user interface
- Ideal for MMA, MIG/MAG and pulsed MIG/MAG, TIG DC welding process
- URANOS NX could be connected to the exclusive Böhler Welding Weld@Net® Production Control Monitor software to monitor and control your welding
- URANOS NX can be used in automatic and/or robotized welding systems by activating the dedicating operating software
URANOS NX - The next welding evolution
MIG/MAG Welding Processes
The Digital Welding technology represents a new approach to welding and guarantees consistent and repeatable performance in pulsed MIG/MAG applications. PulsDrive, QuickPulse and CladPulse are the pulsed MIG/MAG processes developed by Böhler Welding, offering extraordinary maneuverbility, excellent finish and optimized metallurgical properties with a perfect combination of productivity and appearance.
- New wave form developed entirely by Böhler Welding
- ArcDrive satisfies all MIG/MAG needs
- Ideal for carbon steel
- A stable and highly reactive arc for easier welding, even in difficult welding positions
- Less spatter, meaning less reworking
- Designed and developed to maximize productivity and speed
- Easy to start and to use
- An accurate, focused weld bead, thanks to excellent welding control
- Improved penetration with optimized fusion of edges and roots
- Thanks to perfect arc control, welding speed can be up to 50% faster than in a standard MIG/MAG process
- New wave form developed entirely by Böhler Welding
- 100% digital control of the welding arc
- Extremely rapid response and tuning of welding parameters for consistently excellent results
- Extremely stable welding arc thanks to uniform, pulsed transfer of material in tiny, constant-size droplets
- Almost total absence of spatter, meaning less reworking
- Designed and developed to maximize productivity and speed
- Extremely stable and concentrated arc
- Increased welding speed +50%
- Reduction of heat-effected zone
- No undercutting and less deformation
- Specially developed for cladding application
- High-Deposition rate welding arc
- Careful set up to achieve the minimum dilution with the base metal
- Minimal penetration and absence of defects
- High corrosion resistance
TIG DC Welding Processes
Böhler welding has a wide range of TIG DC welding processes. Any welding process has a specific task, and the customer can choose the suitable welding solution according his need. All the TIG DC processes implemented in our inverters are designed, developed and tested by Böhler Welding and they are premium level as market positioning. DCDrive, DCPulse, FastPulse and EasyArc are the TIG DC processes developed by Böhler Welding, offering high quality welding for stainless steel, aluminum and carbon steel and excellent weld bead finish.
- Proven process with a huge number of installations
- Great precision, quality and performance in all applications
- Quick and reliable ignition ensures smoothly work and efficient operational
- Very silent process and optimal working condition
- Digitally controlled arc process
- Arc pulse from an high and a low level
- The welding arc is "focused" by reducing the effect of "voltage loss"
- The enhanced arc control produces an excellent weld bead
- Reduction of thermal strain
- Process with high frequency pulsation from 20 to 2500 Hz
- Maximum arc focusing, welding speed increases: +65% to 90%
- The high stability arc produces a tight and regular weld bead
- Thermal strain is reduced to the minimum
- Process with high frequency pulsation from 20 to 2500 Hz
- Maximum arc focusing, welding speed increases: +65% to 90%
- The high stability arc produces a tight and regular weld bead
- Thermal strain is reduced to the minimum
Master Software
URANOS NX GSM must be activated with a Master software, the operating software for the welding functionality. The Master software can be chosen by the customer according its specific welding job. Different master software are available for different materials and activities.
Master Software 1
Unalloyed Steel
- MIG/MAG welding
- Böhler Arc welding programs
- Universal Arc welding programs
- Designed for carbon steel welding
Master Software 2
Unalloyed Steel
- Pulsed MIG/MAG welding
- Böhler Arc welding programs
- Universal Arc welding programs
- Designed for carbon steel welding
Master Software 3
Unalloyed Steel
- MIG/MAG and pulsed MIG/MAG welding
- Böhler Arc welding programs
- Universal Arc welding programs
- Designed for carbon steel welding
Master Software 4
High Alloyed Steel
- MIG/MAG and pulsed MIG/MAG welding
- Böhler Arc welding programs
- Universal Arc welding programs
- Designed for stainless steel welding
Master Software 5
AL & CU Alloy
- MIG/MAG and pulsed MIG/MAG welding
- Böhler Arc welding programs
- Universal Arc welding programs
- For aluminum alloy and copper alloy welding
Master Software 6
Unalloyed & High Alloyed Steel Aluminum Alloy
- MIG/MAG and pulsed MIG/MAG welding
- Böhler Arc welding programs & Universal Arc welding programs
- For carbon steel, stainless steel and aluminium welding
Master Software
URANOS NX PMC/MTE
Unalloyed & Highalloyed Steel Aluminium Alloy
- MIG/MAG welding
- Böhler Arc & universal arc welding programs
- For carbon steel, stainless steel and aluminium welding
- Factory set
Welding Program Packages
Böhler Welding offers a wide variety of MIG/MAG welding program packages for many materials: carbon steel, stainless steel, aluminum and many other. By using our welding programs settings are recall automatically based on welding conditions (material, thickness, gas, wire, speed) and are dynamically controlled and balanced by a microprocessor control system throughout the welding process. This solution delivers excellent results in terms of productivity, quality and finish in all conditions and all applications. We provides a range of synergic programs and we continuously develop new programs to meet specific user requests. We offer to our customers the Böhler Arc Library with Solid Wire, Metal Cored, Flux cored and many others Böhler Welding consumables or the Universal Arc welding programs with standard consumables.
For more info about the available MIG/MAG welding program package, contact the nearest Böhler Welding Partner:
Böhler Welding 5 Years Warranty Program
Böhler Welding machines are covered by a five-year warranty (requires registration), giving customers the peace of mind of knowing that they have purchased a high-quality power source.
Robust, reliable design and regular maintenance - guarantees a long product life cycle.
You need a five-year warranty for your machine? No problem. Simply fill out the warranty form and we will send you a warranty confirmation.
