voestalpine Wire Technology

Flat and Shaped Wire for Demanding Applications

Our drawn and rolled flat and shaped wire with cross sections of around 2 mm² to 200 mm² meet the very highest quality standards. We manufacture a wide variety of profiles including rectangular and trapezoidal shaped wire, flat wire, square-cut and semicircular wire, as well as customized shapes for a variety of potential applications.

Our long-term partnerships with customers in the oil and gas industry, the automotive sector, in ropeway systems, in mechanical engineering and in agriculture underscore the trust placed in the quality of our products and our power to innovate at voestalpine Wire Technology.

Our Strengths

Our specialists at voestalpine Wire Technology enjoy the challenge of producing flat and shaped wire with excellent properties.

  • Research and development partnerships with leading industrial enterprises and universities
  • Pioneer in materials testing and simulating cold and warm heading
  • High added value and influencing of all process parameters along the production chain
  • Collected expert know-how along the entire integrated production process
  • Strict adherence to schedules, flexibility and partnership with our customers

  • Steel grades

    • Low alloyed carbon steel (carbon content up to max. 1,05%)
    • High alloy special steel & special grades upon request



    Types

    K + U + C shaped: air-patented (stelmor); lead-patented
    K + GKZ + U + C + AC shaped + annealed on spheroidised carbide
    K+ GKZ + K + U + C + AC + LC shaped + annealed on spheroidised carbide + skin-pass



    Further types upon request.

  • Inner diameter 400 / 500 / 600 mm
    Outer diameter max. 1.250 mm
    Height 300 - 500 mm
    Max. Weight 450 - 3.000 kg



    Further specifications upon request.

    • Flat wire
    • Rectangular and Trapezodial
    • Square and Hexagonal
    • Oval and Half round
    • Special shapes on request

  • Surface

    • witeco® - surface technology
    • Bright
    • Phosphated
    • Oiled
    • Oil dipped for final annealed wire



    Quality management

    • ISO 9001
    • ISO 14001
    • EMAS III
    • IATF 16949
    • ISO 17025
    • ISO 45001
    • ISO 50001

SUCCESS STORIES:

Galvanized flat wire as an important part of the global energy supply

Flat wires from the voestalpine Wire Austria production site in Bruck/Mur are used for the armouring of high-voltage cables for deep-sea applications, high-voltage XLPE cables, as well as for offshore wind farms and onshore power plants.

To the article "Galvanized flat wire"



Rolling line for profiles

6.000 bar success pressure - How is profiled wire involved in gentle food preservation? The answers lie in the rolling line for profiles (KPWA for short). With a pressure of 6.000 bar, food is gently preserved in high-pressure containers. To illustrate: This corresponds to a pressure at a sea depth of 60 km. Such special processes require high-performance technology and extraordinary machine components.

To the article "Rolling line for profiles"
