Long Products (round bars & flat bars)
As one of the world’s most renowned stainless-steel manufacturers, our mills produce aerospace flat & round bars that have been certified by the aerospace industry. The latest vacuum melting technologies (VIM, VAR) and metallurgical knowledge accumulated since 1870 make us a reliable partner for international aerospace and aircraft manufacturers
Aerospace round and flat bars
Dimensions:
| BAR Steel rolled | BAR STEEL forged |
| round: 12.5 – 150 mm (0.49 – 5.91″) | round: 110 – 1200 mm (4.33 – 47.24″) |
| square: 15 – 130 mm (0.59 – 5.12″) | square: 90 – 1200 mm (3.54 – 47.24″) |
| flat: width thickness | flat: width thickness |
| 15 – 60 mm (0.59 – 2.36″) 5 – 41 mm (0.20 – 1.61″) | 120 50 mm (4.72 – 1.97″) minimum |
| 60 – 200 mm (2.26 – 7.87″) 5 – 86 mm (0.20 – 3.39″) | 1600 1000 mm (62.99 – 39.37″) maximum |
| 100 – 300 mm (3.94 – 11.81″) 15 – 80 mm (0.59 – 31.5″) | Ratio width / thickness maximum 10:1 |
| ROLLED WIRE | |
| drawn (dia.): 1.0 – 12.0 mm (0.04 – 0.47″) | |
| precision shaped round: 1.0 – 28.0 mm (0.04 – 1.10″) | |
| precision shaped flat: 0.5 – 40.0 mm2 (0.00078 – 0.062 sq.in.) | |
| Surface condition | |
| – blasted / milled / peeled / turned | |
| – peeled and polished | |
| – belt grinded | |
| – ground and polished |
Specials Notes:
DFARS:
DFARS 252.225.7014: Clause c1, DFARS 225.872
Buy American:
Austria is listed as a qualified country in DFARS 225.872-1, 252.225-7012 because the United States and Austria have signed reciprocal defense procurement MoU.
Austrian material may be used in “Buy America” applications where the total value of Austrian material is less than 50% of the value of the component.
voestalpine BOHLER Edelstahl is an eligible supply source according to DFARS 252.225-7009.
Aerospace round and flat bars
Materials:
Selection according to BS
| Brand | BS | Market Grade | UNS | ASTM | Melting route | Others | Industry Specifications |
| BÖHLER N352S1 | S80 | 431 | EAF | Z15Cn17-03 | |||
| BÖHLER E108 | S82S156 | EAF or EAF-VAR | EN176716NCD17 | Liebherr LAT 1-9043 | |||
| BÖHLER V141 | S97S140S154 | EAF | Bombardier EMCM-001-1013 | ||||
| BÖHLER V118S1 | S98S99 | EAF | ~40NiMoCr10-5 | Bombardier EMCM-001-1013 | |||
| BÖHLER A750 | S130 | EAF | X5CrNiNb18-10Z6CNNB1810 | Airbus ZBF1109,ZBF301438Boeing DMS QPL 2201 | |||
| BÖHLER V358 | S132 | E40CDV12 | EAF-VAR | E40CDV12 | |||
| BÖHLER T552 | S151 | Jethete | EAF | Rolls Royce MSRR 6502Snecma DMD 0235-20, DMD 0237-20 | |||
| BÖHLER V250AMS | S162 | Maraging250 | VIM-VAR | EZ2NKD18-8-5 | Liebherr LAT 1-9018 | ||
| BÖHLER V250 | S162 | Maraging250 | VIM-VA | X2NiCoMo 18-8-5 | Messier Dowty MAT102 |
Selection according to DIN
| Brand | WL | Market Grade | UNS | ASTM | Melting route | Others | Industry Specifications |
| BÖHLER N695 | 1.35441.4125 | S4400 | EAF orEAF-VAR | X105CrMo17X102CrMo17Z100CD17 | |||
| BÖHLER R250 | 1.3551 ~ | M50 | VIM-VAR | E80DCV40 | GE C50TF56 P&W PWA793,CPW 378 Snecma DMD 119-20 | ||
| BÖHLER N352 | 1.4044 | 431 | EAF | Z15Cn17-03 | Airbus ZBF1109, IPSWL 1.4044.6 Liebherr LAT1-9070 CI.A Cond.2 | ||
| BÖHLER N360 | 1.4108 | X30 | EAF-ESR | X30CrMoN15-1 | FAG FL-LA2486 1SX | ||
| BÖHLERN709 | 1.4534 | 13-8 Mo | S13800 | A564 | VIM-VAR | EZ3CNDA 13-8X3CrNiMoAI13-8-2EN 3357EN 3358 | Airbus ZBF1109, ZBF3011438, IPSWL1.4534.4-01,ABS 5422C,ABS 5259A, IPS 01-04-004 Bombardier EMCM-001-1013 Liebherr LAT1-9048 |
| BÖHLER N700 | 1.4542 | 17-4 PH | S17400 | A564 | EAF | Z6CNU17.0X5CrNiCuNb17 4 4 | Boeing DMS QPL 2201, AMS 5643 P&W CPW-S 5643 Snecma DMD 229-20 |
| BÖHLER N701 | 1.4545 | 15-5 PH | S15500 | A564 | EAF-VAR | Z6CNU17.04X5CrNiCu15.05EN 2815EN 2817 | Airbus/Eurocopter ASNA 3294, ASNA 3297, ASNA 6116, ABS 5455, IPS 01-04-003-02 Aircelle HMDM0022 Boeing D1 4426 (PC660) Bombardier EMCM-001-1013 Goodrich _AMS5659 Liebherr LAT 1-9037 |
| BÖHLER A750 | 1.4546 | EAF | X5CrNiNb 18-10Z6CNNb1810 | Airbus ZBF1109, ZBF301438 Boeing DMS QPL 2201 | |||
| BÖHLER N700 | 1.4548 | 17-4 PH | S17400 | A564 | EAF-VAR | EZ6CNU17.04X5CrNiCuNb17 4 4 | Airbus ZBF1109, ZBF301438, IPSWL1.4548 Alenia P19X316 |
| BÖHLER T670 | 1.4594 | 520B | S15500 | A564 | S143, S144 | ||
| BÖHLER T552 | 1.4939 | Jethete | S64152 | EAF or EAF-ESR | Z12CNDV12 | GE C50TF68Snecma DMD 0242-20Turbomeca AMS5719 | |
| BÖHLER T200SA | 1.49431.4944 | A286 | S66286 | EAF-ESR | EnZ6NCT25EN2303 | Rolls Royce MSRR 6532 | |
| BÖHLER T200 | 1.4944 | A286 | S66286 | EAF-ESR | EnZ6NCT25EN2303 | Snecma DMD 0274-22 Turbomeca AMS 5732, MSRR 6688 | |
| BÖHLER V300 | 1.6354 | Maraging 300 | VIM-VAR | EZ2NKD18~X2NiCoMo18-9-5 | |||
| BÖHLER V250 | 1.6359 | Maraging 300 | VIM-VAR | X2NiCoMo18-9-5 | Messier Dowty MAT102 | ||
| BÖHLER V145 | 1.6604 | 30CND8 | VIM-VAR | 30CND830CrNiMo8 | Airbus ZBF1109, ZBF301438 | ||
| BÖHLER E108 | 1.6722 | EAF or EAF-VAR | EN276716NCD17 | Liebherr LAT 1-9043 | |||
| BÖHLER V118S1 | 1.6745 | EAF | ~40NiMoCr10-5 | Bombardier EMCM-001-1013 | |||
| BÖHLER V354 | 1.77341.7736 | 15CDV6 | EAF | E15CDV6~14CrMoV6 9 | Airbus ZBF1109, ZBF301438 | ||
| BÖHLER V361 | 1.7765 ~ | E32CDV13 | VIM-VAR | E32CDV13 | Eurocopter ASNA 6128, ANSA6123 | ||
| BÖHLER V358 | 1.8523 | E32CDV13 | EAF-VAR | E40CDV12 | |||
| BÖHLER L090 | 2.4632 | Alloy 90 | N07090 | B637 | VIM-VAR | NICK20TaNiCr20Co18Ti | MTU MTS 1042-2 |
| BÖHLER L303 | 2.4668 | Waspaloy | N07001 | B637 | VIM-VAR | NC20K14NiCr19Co14MoTi | Snecma DMD 0426-22 on request |
| BÖHLER LHX | 2.4665 | Alloy X | N06002 | B572 | VIM-ESR | N22FeD | GE B50TF31-A Snecma DMD 491-23 on request |
| BÖHLER L718 | 2.4668 | Alloy 718 | N07718 | B637 | VIM-VAR | NiCr19NbMoNC19FCNb | Boeing D1 4426 (PC696) GE B50TF15 A/D/E, C50TF6 only meeting process and chemistry, spec if for forged parts B50A809 Goodrich AMS5662MTU MTS 1424-1, MTS 1424-3 P&W PWA-S-5662 CI.2, PWA-S-5663 CI.2 Snecma DMD 424-22 on request |
| BÖHLER L625 | 2.4856 | Alloy 625 | N06002 | B446-03 G1B564-06A | VIM-ESR | NiCr22Mo9NbNC22DNb | Honeywell EMS 55-425 cond B Snecma DMD 491-23 on request |
Selection according to AMS
| Brand | AMS | Market Grade | UNS | ASTM | Melting route | Others | Industry Specifications |
| BÖHLERN709 | 5629 | 13-8 Mo | S13800 | A564 | VIM-VAR | EZ3CNDA 13-8X3CrNiMoAI13-8-2EN 3357EN 3358 | Airbus ZBF1109, ZBF301438, IPSWL 1.4534.4-01, ABS 5442C, ABS 5259A, IPS 01-04-004 Bombardier EMCM-001-1013 Liebherr LAT1-9048 |
| BÖHLERN700 | 5643 | 17-4 PH | S17400 | A564 | VIM-ESR | Honeywell EMS 55-425 cond B Snecma DMD 491-23 on request | |
| BÖHLER A750 | 5646 | EAF | X5CrNiNb1810Z6CNNb1810 | Airbus ZBF1109, ZBF30 1438Boeing DMS QPL 2201 | |||
| BÖHLER N701 | 5659 | 15-5 PH | S15500 | A564 | EAF-VAR | EZ5CNU15.15X5CrNiCu15.05EN 2815EN 2817 | Airbus/Eurocopter ASNA 3294, ASNA 3297, ASNA 6116, ABS 5750, ABS 5455, IPS 01-04-003-02 Aircelle HDMM0022 Boeing D1 4426 (PC660) Bombardier EMCM-001-1013 Goodrich _AMS5659 Liebherr LAT 1-9037 |
| BÖHLER N701AMS | 5659 | 15-5 PH | A564 | EAF-VAR | EZ5CNU15.15X5CrNiCu15.05 | Liebherr LAT 1-9037 Cond A, only AMS5659 | |
| BÖHLER L625 | 5666 | Alloy 625 | N06002 | B446-03 G1B564-06a | VIM-ESR | NiCr22Mo9NbNC22DNb | Honeywell EMS 55425P cond B Snecma DMD 491-23 on request |
| BÖHLER T552 | 5719 | Jethete | S64152 | EAF or EAF-ESR | Z12CNDV12 | GE C50TF68 Snecma DMD 0242-20 Turbomeca AMS5719 | |
| BÖHLER LHX | 5754 | Alloy X | N06002 | B572 | VIM-ESR | NC22FeD | GE B50TF31-A Snecma DMD 491-23 on request |
| BÖHLER T671SB | 5773 | Custom 450 | EAF-ESR | ||||
| BÖHLER L090 | 5829 | Alloy 90 | N07090 | B637 | VIM-VAR | NCK20TANiCr20Co18Ti | MTU MTS 1042-2 |
| BÖHLER N360 | 5898 | X30 | EAF-ESR | X30CrMoN15-1 | FAG FL-LA2486 1SX | ||
| BÖHLER E105 | 6265 | 9310 | EAF-VAR or VIM-VAR | AISI 9310 | Agusta 199-20-005 | ||
| BÖHLER R350 | 6278 | M50 Nil | VIM-VAR | E13DCNV40 | GE B50TF211 | ||
| BÖHLER V124SC | 6414 | 4340 | GA3400 | EAF-ESR or VIM-VAR | SAE 4340~40NiCrMo6~E40NCD7 | Agusta 199-20-007 Bombardier EMCM-001-1013 | |
| BÖHLER R100 | 6444 | 52100 | EAF-VAR or VIM-VAR | 100Cr6E100C6 | |||
| BÖHLER V361 | 6481 | E32CDV113 | VIM-VAR | E32CDV13 | Eurocopter ASNA 6128, ANSA6123 | ||
| BÖHLER R250 | 6491 | M50 | VIM-VAR | E80DCV40 | GE C50TF56 P&W PWA793,CPW 378 Snecma DMD119-20 | ||
| BÖHLER V250AMS | 6512 | Maraging 250 | VIM-VAR | EZ2NKD18-8-5 | Liebherr LAT 1-9018 | ||
| BÖHLER V300 | 6514 | Maraging 300 | VIM-VAR | EZ2NKD18~X2NiCoMo18-9-5 | |||
| BÖHLER N695 | 56185630 | 440C | S44004 | EAF or EAF-VAR | X105CrMo17X102CrMo17Z100CD17 | ||
| BÖHLER N700 | 56225643 | 17-4 PH | A564 | EAF-VAR | EZ6CNU17.04X5CrNiCuNb17 44 | Airbus ZBF1109, ZBF301438, IPSWL1.4548 Alenia P19X316 | |
| BÖHLER L718 | 56625663 | Alloy 718 | N07718 | B637 | VIM-VAR | NiCr19NbMoNC19FCNb | Boeing D1 4426 (PC696) GE B50TF15 A/D/E, C50TF6 only melting process and chemistry, spec is for forged parts, B50A809 Goodrich AMS5662 MTU MTS 1424-1, MTS 1424-3 P&W PWA-S-5662 Cl.2, PWA-S-5663 Cl.2 Snecma DMD 424-22 on request |
| BÖHLER L303 | 570457065707 | Waspaloy | N07001 | B637 | VIM-VAR | NC20K14NiCr19Co14MoTi | Snecma DMD 0426-22 on request |
| BÖHLER T200 | 57315732 | A286 | S66286 | B637 | VIM-ESR | EnZ6NCT25EN2303 | Honeywell EMS 55-425 condB Snecma DMD 491-23 on request |
